Carbon Scout Pro - 20000lb Extreme Duty Truck Winch

Carbon Offroad Scout Pro 20K Winch
Heavy-Duty Power for Serious Recovery

The Carbon Offroad Scout Pro 20K Winch is engineered for the toughest recovery situations — delivering an incredible 20,000 lb pulling capacity powered by a robust 7 HP motor. Built for full-size trucks and heavy-duty applications, this 37.2 kg winch combines strength, reliability, and performance in one rugged package.

Featuring a 3-stage planetary gearbox for smooth and efficient operation, an automatic load-holding brake for maximum safety, and a sealed 600 A solenoid for dependable power delivery in all conditions, the Scout Pro 20K is designed to perform when it matters most.

Supplied with both wired and wireless remote controls, this winch gives you complete flexibility and control during every recovery.

Built tough for extreme off-road recovery, the Carbon Offroad Scout Pro 20K sets the benchmark for power, durability, and performance in the heavy-duty winch category.

• Part number: CW-XD20
• Rated line pull: 20000 lbs, (9072kg) single-line
• Motor: 12V DC 7 HP series wound motor (24V option available)
• Remote Control: Wired with 3.6m lead
• Wireless Remote Control: Included
• Geartrain: 3-Stage Planetary
• Gear Ratio: 345:1
• Rotating Ring Gear
• Brake: Automatic brake in the motor bracket
• Fairlead: Carbon Offroad MEGAPRO Premium CNC billet type 3 hard anodised multi position fairlead
• Lifetime Mechanical Warranty
• 5 Year Electrical Warranty
• 5 Year Water Ingress Protection Warranty
• Synthetic Rope: 25m x 13mm diameter
• Drum Diameter/Length: 88mm x 224mm
• Mounting Bolt Pattern: 254mm x 114.3mm
• Recommended Battery: 650 CCA minimum for winching
• Winch Dimensions (L x W x H): 579 x 192 x 224mm
• Packing Dimensions (L x W x H): 640 x 250 x 345mm
• Winch weight with synthetic rope attached: 30kg
• Winch weight including synthetic rope, control box complete with cables, mounting bolts & fairlead: 37kg
