Brace Kit - Warn XD9000/9.5XP/M8000 winches

Upgrade and protect your winch with our heavy-duty Extended Brace Kit, engineered specifically for Warn XD9000, Warn 9.5XP, and Warn M8000 models.

Stronger Than Factory. Built for Real-World Recovery.

The factory tie bar setup used on many Warn winches is known to fail when rope spools unevenly to one side. When this happens, the tie bars can tear away from the winch, often causing serious damage to the winch support plates and, in many cases, turning an expensive winch into a write-off.

Our Extended Brace Kit is designed to eliminate that weak point.

Engineered for Strength & Clearance

• 16mm 2011 alloy tie bar repositioned 27mm further out from the winch body

• Increased drum clearance to prevent rope build-up damage

• Reinforced with 4mm 304 stainless steel extension plates

• Adds significant structural strength to the rear of the winch

By moving the tie bar further away from the drum, this kit dramatically reduces the risk of failure caused by uneven rope spooling, one of the most common causes of winch damage.

Bolt-On Installation – No Modifications Required

No cutting.
No fabrication.
No specialist tools.

Simply bolt the kit on using the supplied hardware and follow the included instructions. Installation is straightforward, making this one of the easiest and most effective winch upgrades you can do.

Why Choose Our Warn Winch Extended Brace Kit?

• Protects your winch from costly damage

• Prevents factory tie bar failure

• Adds strength and durability

• Improves drum clearance

• Complete kit supplied with all required components

• Only $10 more expensive than just a set or Warn tie bars

If you rely on your Warn winch for serious off-road recovery, don’t leave its weakest point unprotected. Upgrade your Warn XD9000, 9.5XP, or M8000 with a heavy-duty extended brace kit designed to handle real-world abuse and winch with confidence.
